Monitor Audio C1L 9" In-Ceiling Speaker
If the ceiling has a bedroom or other living space above it, or is part of an escape route, building regulations require each speaker to have a fire hood. Hoods also cut sound leaking into the room above.
Allow about 10m per speaker for a typical run back to the amplifier. Webro 16/2 LSZH (low smoke, zero halogen) is the right cable for runs in ceilings and walls.
Request a quote
Monitor Audio Creator Series is sold by quotation. Choose your models and quantities, and we'll email you a quote with a secure link to pay online, normally within one working day.
The Monitor Audio C1L is a large-format in-ceiling speaker designed for anyone who wants genuine high-fidelity sound without a premium price tag. Its substantial 9" mid-bass driver makes it particularly well suited to bigger rooms such as open-plan kitchens, living areas, home cinemas and commercial spaces like shops, offices and restaurants where background music needs real presence and depth.
Why we like it
- Powerful 9" C-CAM mid-bass driver delivers extended, authoritative bass
- 1.25" C-CAM tweeter adds detailed, controlled high frequencies
- Wide 30Hz-25kHz frequency response for a genuinely full-range performance
- Quik-Link connector makes wiring fast and tool-free
- Tri-Grip II mounting system ensures a stable, rattle-free installation
Installation notes
The C1L requires a 248mm cut-out and a mounting depth of 99mm, so check loft or ceiling void clearance before installing. A pre-construction bracket (CL-B) is available for new-build projects. Given its 75W power handling and 8 ohm nominal impedance, the C1L pairs well with a dedicated multi-room amplifier such as a Sonos Amp or a WiiM Amp for streamed background music, or with a traditional AV receiver in home cinema applications. The supplied paintable round grille allows it to blend into any ceiling colour scheme.
Specifications
| System Format | 2-Way |
| Frequency Response (-6dB) | 30 Hz - 25 kHz |
| Nominal Impedance | 8 ohm |
| Minimum Impedance | 6.4 ohm @ 150 Hz |
| Sensitivity | 88 dB (2.83Vrms @ 1m) |
| Maximum Peak SPL | 116 dB |
| Continuous Power Handling | 75W RMS |
| Recommended Amplifier Power | 40-150W RMS into 8 ohm |
| Drive Units | 1 x 9" C-CAM mid-bass driver, 1 x 1.25" C-CAM tweeter |
| Crossover Frequency | 2 kHz |
| Mounting Depth | 99mm |
| Cut-Out Hole Diameter | 248mm |
| External Dimensions | 278 x 278 x 103mm |
| Weight | 2.5kg |
| Cabinet Finish | Matte black & orange |
